Protecting Buildings from Wind and Rain

This system is designed specifically for exterior perimeter walls. Its primary function is to protect the building from wind-driven rain and external weather conditions while maintaining a comfortable interior environment.

We install a waterproof and vapor-permeable membrane on the frame side. This membrane prevents rainwater penetration into the wall structure while allowing internal water vapor to escape.

The ventilation cavity can also accommodate exterior insulation panels, improving the overall thermal performance of the building envelope.

Our factory is located in Qidong, Jiangsu, and covers 3,000 square meters. We have 30 workers and our own R&D team.

Every batch of bricks is inspected during incoming material checks and before shipment. We test dimensions, flatness, and water absorption. The water absorption rate meets our strict quality standards.

The Terracotta Brick Exterior Dry Cladding System provides a reliable protective layer against harsh weather conditions.

Fire Safety and Reliable Performance

Fire safety is one of the key advantages of this system.

Terracotta bricks are classified as Class A1 non-combustible materials. They do not burn in fire conditions and do not produce toxic smoke or harmful emissions.

We design and manufacture our systems according to the GB/T 21086-2007 standard for building curtain walls.

The brackets are made of 304 or 316 stainless steel. A 6 to 12 mm joint is maintained between the bricks to accommodate thermal expansion and movement.

We provide a 10-year warranty. Standard orders can be completed within 25 days, and our monthly production capacity reaches 150,000 square meters.

We welcome third-party inspections and provide photo and video updates during the production process.

We also provide free samples. Custom sample development takes 15 to 40 days.

The Terracotta Brick Exterior Dry Cladding System is a safe and reliable solution for different types of building envelopes.

Built to Withstand Tough Conditions

The system weight ranges from 18 to 42 kg per square meter, depending on the brick type.

During installation, we consider local wind pressure requirements and water penetration standards to ensure reliable performance.

The main frame spacing should not exceed 1000 mm.

The total system thickness is 180 to 200 mm with insulation and 130 to 150 mm without insulation.

The minimum order quantity is 300 square meters. Customers can mix different colors or models within one order.

We follow a five-step process to ensure on-time delivery. This includes order review, safety stock preparation, production scheduling, quality control, and logistics planning.

If unexpected issues occur, we will inform customers in advance and provide alternative solutions.

The Terracotta Brick Exterior Dry Cladding System provides long-term protection, fire safety, and reliable facade performance for modern buildings.

Technical Parameters

Parameter	Specification / Value
System Positioning	Building Exterior Perimeter Wall
Fire Rating	Class A1 Non-Combustible
Waterproofing	Vapor-Permeable Membrane on Frame Side
Standard Lead Time	25 Days
Warranty	10 Years
